| Model | Performance at B0W35 | Performance at W10W35 | Performance at W40W65 | Maximum heating water temperature | |||
| kW | COP | kW | COP | kW | COP | °C | |
| AQ40ZHX | 13.8 | 3.94 | 19.62 | 5.57 | 38.56 | 5.92 | 82 |
| AQ50ZHX | 18.59 | 4.19 | 26.1 | 5.82 | 51.3 | 6.19 | 82 |
| AQ60ZHX | 23.39 | 4.09 | 32.91 | 5.61 | 63.58 | 5.76 | 82 |
| AQ75ZHX | 28.24 | 4.13 | 39.47 | 5.67 | 76.31 | 5.86 | 82 |
| AQ100.2ZHX | 37.18 | 4.09 | 52.21 | 5.69 | 96.78 | 5.78 | 82 |
All units supplied as standard with Regulation PLUS (pCO5): Designed for multiple-circuit heating systems. 2 independent auxilliary heating circuits including mixing. 2-zone space temperature, can be expanded up to 6 heating circuits with optional extra expansion board.
Connecting the Master Therm heat pump to the internet allows it to be controlled from anywhere via the web browser on Mastertherm.online or via an app on a mobile phone or tablet. You are thus in full control of your home’s heat, which is within easy reach. Continuous service supervision and remote diagnostics included.
The control system also can cooperate with photovoltaic inverter and can predict future electricity spot prices. It makes the heat pump's operation as economical as possible.
Please see summary of optional equipment that can be added to your heat pump during manufacturing for your bespoke solution.
Advanced online control and remote service access.
Up to 6 heating circuits + SHW, for regulation PLUS (pCO5) only.
Parametrization, temperature compensation, humidity sensor, ethernet or wifi internet connection.
Utilising our on-board control strategy we can provide heating and cooling simulatenously for maximum performance and efficiency.
Exclusive for ground-to-water heat pumps. Direct heat extraction from the interior of the ground collector or borehole. Extremely economical summer cooling of the building without need for compressor work.
For accurate reading and storing of electrical consumption.
For connecting multiple units together for higher capacity demands.
Adaptation for use on bottom or surface water. Evaporator more resistant to sediment (coax) and different electrical equipment.
